自锁式包塑不锈钢扎带
PVC Covered Stainless Steel Cable Tie-ball self-lock
产品特性 Product Features
材质：不锈钢304/316，外包PVC电缆塑料
特性：耐酸、耐腐蚀、不易燃烧，滚珠自锁是结构使其具有使用简单快捷，不可解开等优势。
工作范围：-40℃+100℃
Characteristic:They have an unique ball locking with PVC covering mechanism that allow easily and quickly installed and notundone;
Working temperature:-40℃+100℃；
High resistance to acetic acid,alkali acid sulphuric acid,corrode...etc;High tensile strength:Non-flammability;
Material:Stainless Steel 304/316
产品参数如下表：
|
规格型号 Part number |
宽度(mm) Width |
长度(mm) Length |
厚度(mm) Thickness |
捆扎直径(mm) Max bundle dia |
拉力(KGS) Min loop tensile |
| JHCC-5.6X150 | 5.6 | 150 | 1.0 | 37 | 35 |
| JHCC-5.6X200 | 5.6 | 200 | 1.0 | 50 | 35 |
| JHCC-5.6X250 | 5.6 | 250 | 1.0 | 63 | 35 |
| JHCC-5.6X300 | 5.6 | 300 | 1.0 | 76 | 35 |
| JHCC-5.6X350 | 5.6 | 350 | 1.0 | 89 | 35 |
| JHCC-5.6X400 | 5.6 | 400 | 1.0 | 102 | 35 |
| JHCC-5.6X450 | 5.6 | 450 | 1.0 | 115 | 35 |
| JHCC-5.6X500 | 5.6 | 500 | 1.0 | 128 | 35 |
| JHCC-5.6X600 | 5.6 | 600 | 1.0 | 154 | 35 |
| JHCC-9X150 | 9 | 150 | 1.0 | 37 | 45 |
| JHCC-9X200 | 9 | 200 | 1.0 | 50 | 45 |
| JHCC-9X250 | 9 | 250 | 1.0 | 63 | 45 |
| JHCC-9X300 | 9 | 300 | 1.0 | 76 | 45 |
| JHCC-9X350 | 9 | 350 | 1.0 | 89 | 45 |
| JHCC-9X400 | 9 | 400 | 1.0 | 102 | 45 |
| JHCC-9X450 | 9 | 450 | 1.0 | 115 | 45 |
| JHCC-9X500 | 9 | 500 | 1.0 | 128 | 45 |
| JHCC-9X600 | 9 | 600 | 1.0 | 154 | 45 |
| JHCC-9X800 | 9 | 800 | 1.0 | 225 | 45 |
|
任何长度均可定制，All lenght are available |
|||||
